MenuOverlay

The Menu Overlay is the main overlays it allow you to create HUD, Menus, Inventories, ETC... This is also what you will use to create web app with the EGE

How to Initialize the Menu Overlay?

To initialize the Menu Overlay simply call the function AddNewMenuOverlay from the GUI group.

Class Details

Functions:

Initialization & Main Functions

Name

Arguments

Return

Description

Init

String: BaseID - HMTL ID defining the position in the DOM of the tab. (Automatically set by AddNewMenuOverlay).
String: RegistryName - Name that define this overlay, all children IDs will start by this.

VOID

This function Initialized every part of the viewer: HMTL, CSS, Data, Events, etc...

It will be generated in the defined ID and all HTML IDs used for this will start by the RegistryName defined in arguments.

Launch

None

VOID

Launch all systems required by the this and will call all children launch.

Setters Functions

Name	Arguments	Return	Description
IsFillingViewport	Boolean: IsFilling - Specified if filling (See description)	VOID	Setup an Overlay IsFilling mean it cover the whole viewport, so it will lock all interaction behind it. If you set it has fault all the interaction will go through (no more event on the overlay - in that case use ForceInteraction function to make it interactive).
SetBackgroundColor	Color: BG - Background Color	VOID	Setup the background color.
SetBackgroundImage	String: URL - link of the image @Nullable Function: SBICallback - function called when the image is loaded.	VOID	Setup the background image.
Reset	None	VOID	Will destroy and remove everything in the overlay.

Design & Other Functions

Name

Arguments

Return

Description

AddWidget

WidgetType: Type - Define which widget you want.
String: Name - Name of this widgets.

Widgets

Will add a selected children widgets in itself and return it.

Note: The children will always they're IDs starting by the parent name, so time it's not in the same family you can add an identical name.

AddPopUp

String: Name - Name of this popup.

PopUp

Add a new PopUp window to the overlay.

Interaction Functions

Name	Arguments	Return	Description
Movable	Integer: WhichButton - The mouse button ID that will move the overlay.	VOID	This function will authorize the overlays to move freely on a 2D plane when the selected mouse button is hold. This function will create all events and will change cursor type to grab .
AddClick	Function: Down - function called when mouse down. Function: Up - function called when mouse up.	VOID	Set the mouse down and up events.
AddMouseMove	Function: Func - function called when mouse moves.	VOID	Set the mouse move events.
AddInteractiveToolBox	Function: AITBCallback - function called when all EE modules are loaded.	InteractiveToolBox	Set an InteractiveToolBox working with this overlay (it return it for setters).

Linker Functions

Name	Arguments	Return	Description
CreateLink	Position: Pos - Where the linker starting.	Boolean	It create create a linker at Pos. This linker will now be attached to the mouse. Send back a Boolean if the linker has been created.
CancelLink	None	VOID	If the link is still active (still following cursor) then use this function to cancel this.
ValidateLink	Position: Pos - Where the linker finishing.	Boolean	Will lock the linker on the defined position. Send back a Boolean if the linker has been locked.
GetLinker	Position: Pos - Where the linker starting. Position: Offset - Where the linker finishing.	Linker	You can retrieved an existing linker by using it's position and offset position.
RemoveLinker	Position: Pos - Where the linker starting. Position: Offset - Where the linker finishing.	None	Will use the position and the offset position to find the linker then it will remove and destroy it.
ClearLinker	None	None	Will remove all linker.

Private Details

All private details are usable but its recommended to not use any of those. It might modify the proper functioning of the class.

Variables (Members):

Main Members

Name	Type	Default Value	Description
id	String	undefined	Global HMTL Id of the viewer (# + name).
registryName	String	undefined	Name of this overlay.
basedId	String	undefined	Where it is located is the existing DOM (its parent).

Information

Name	Type	Default Value	Description
lastMousePos	Position	x: 0 and y: 0	Hold where the mouse in the last move.
shiftX	Integer	0	Hold the x shift the overlays made (When user is moving the overlay). It is used by widgets to recalculate position.
shiftX	Integer	0	Hold the y shift the overlays made (When user is moving the overlay). It is used by widgets to recalculate position.
isMoving	Boolean	false	Used to check if the overlay is moving.
mouseMoveButton	Integer	2	Used to defined which mouse button make the overlay moving

Widgets

Name	Type	Default Value	Description
AllWidget	Widgets[]	[]	Array holding all the Widgets in the overlay.
lastZIndex	Integer	false	To make sure the Widgets are properly layered we decrement this variable each widgets.

Linker

Name	Type	Default Value	Description
allLinker	Linker[]	[]	Array holding all the Linker in the overlay.
lastLinkerID	Integer	0	To make sure the Linker are properly layered we increment this variable each widgets.
doesLinkerActive	Boolean	false	Used to check if a Linker is moving with the cursor.

Tool Box

Name	Type	Default Value	Description
toolBox	toolBox	null	Hold the active toolbox set by AddInteractiveToolBox.
toolBoxIsOpen	Boolean	false	Used to check if toolBox is open.

Functions:

Interaction Functions

Name	Arguments	Return	Description
MoveAll	None	None	This function is called when the overlay is moving to move all overlays components.

Linker Functions

Name	Arguments	Return	Description
MouseMove	JS Event Class: e	None	This function is called when the mouse is moving and a linker is active to make it follow it.

Util Functions

Name	Arguments	Return	Description
GetLinkersID	None	String	Return the linker div ID.

Compatibility

LANGUAGE CLASS: Not compatible.
